Fasto TG260 – High Thermal Conductivity Silicone Paste

Fasto TG260 – High Thermal Conductivity Silicone Paste

Fasto TG260 is a one-part, high-performance, silicone-based non-curing thermally conductive paste formulated for applications requiring efficient and continuous heat transfer at elevated temperatures. With its higher thermal conductivity, Fasto TG260 effectively fills microscopic air gaps between heat-generating components and heat-dissipating surfaces, ensuring rapid heat dissipation and improved system reliability.

Its thick, smooth paste consistency allows easy application using a spatula, forming a uniform thermal interface without curing or hardening over time. Fasto TG260 also provides excellent electrical insulation, weather resistance, and stable performance under continuous and intermittent high-temperature conditions, making it suitable for demanding electronic and electrical assemblies.

- +

Key Features

  • High Thermal Conductivity (2.6 W/m·K)
    Ensures efficient heat dissipation from electronic components.
  • Non-Curing Silicone System
    Maintains stable thermal performance without hardening or cracking.
  • Excellent Electrical Insulation
    Safe for electronic and electrical assemblies.
  • High Temperature Resistance
    Performs reliably under continuous and intermittent high-temperature conditions.
  • Easy Application
    Thick paste consistency allows smooth and uniform spreading.
  • Weather & Aging Resistant
    Maintains performance in harsh operating environments.

Benefits

  • Enhances heat dissipation efficiency
  • Improves reliability and service life of electronic components
  • Prevents overheating-related failures
  • Maintains stable performance without drying or degradation
  • Suitable for demanding industrial and electronic applications
Primary Application Sub-Applications Functional Purpose Key Performance Advantage
LED Assembly Thermal Interface LED modules, LED drivers Heat dissipation High thermal conductivity, non-drying
Power Amplifier Cooling Audio amplifiers, RF modules Prevent overheating Stable at elevated temperatures
Electronic Component Assembly Thermistors, power modules Fill air gaps between surfaces Low thermal resistance
Heat Sink Mounting Metal-to-metal interfaces Improve thermal transfer Uniform gap filling
Industrial Electronics Control panels, automation boards Continuous heat transfer Wide temperature stability
High-Temperature Devices Power converters Thermal management Up to 250°C intermittent resistance
Electrical Insulation Applications Sensitive electronic assemblies Electrical safety High dielectric strength

Surface Preparation

  • Ensure contact surfaces are clean, dry, and free from dust, grease, oil, rust, scale, and other contaminants.
  • Clean surfaces using a suitable Fasto cleaner for best results.

Application Method

  • Apply Fasto TG260 evenly using a spatula on the heat-emitting surface.
  • Ensure the paste fills all micro air gaps between the heat source and heat-radiating surface.
  • Apply sufficient quantity to achieve full contact and wipe off excess material.
  • Avoid excessive application.

Application Temperature

  • Application temperature should be between 5°C and 40°C.
  • Optimum application temperature range is 15°C to 25°C.

Curing Information

  • Non-curing product
  • Remains in paste form throughout service life
  • Provides consistent thermal performance over time

Joint & Thermal Interface Guidelines

  • Designed for thermal interface applications, not structural bonding
  • Ensure uniform layer thickness for optimal heat transfer
  • Avoid air entrapment during application
  • Suitable for continuous and intermittent high-temperature operation
